Cyclone's 'Overshooting Cloud Tops' Seen from Above

Cyclones Overshooting 1
NASA-NOAA's Suomi NPP satellite captured this false-colored night-time image of Cyclone Felleng during the night on Jan. 28, 2013. Felleng is northwest of Madagascar. The image revealed some pretty cold overshooting tops and some interesting gravity waves propagating out from the storm in both the thermal and visible imagery. (Image credit: William Straka, UWM/NASA/NOAA)

Tropical Cyclone Felleng, currently spiraling off the east coast of the island of Madagascar, was caught in a NASA satellite image exhibiting "overshooting cloud tops," a clear sign that it is packing powerful storms.

A NASA statement describes an overshooting cloud top as a domelike protrusion that balloons out from the anvil head of thunderstorm cloud and shoots up into the stratosphere, the layer of the atmosphere above the troposphere. The troposphere is where most weather on Earth occurs.

The overshooting top is indicative of powerful storms because it takes a lot of energy to push through the tropopause, the boundary between the troposphere and stratosphere and where the temperature of the atmosphere goes from decreasing with height to increasing with height. Normally, the vertical growth of clouds stops at the tropopause, the NASA statement says, with the clouds then spreading out horizontally, forming the characteristic anvil shape of most strong thunderstorms.

The Suomi-NPP satellite, run jointly by NASA and the National Oceanic and Atmospheric Administration, captured a false-color thermal image of Felleng's powerful storms during the nighttime hours of Jan. 28 (local Madgascar time). The image shows the extremely cold clouds (the deep reds and pinks toward the center of the storm) that have shot up from the cyclone. (Cyclones are the same phenomenon as hurricanes and typhoons; they are just called different names in different ocean basins.)

The images showed that Felleng had strengthened considerably since the previous day, with bands of convective thunderstorms wrapping more tightly around the storm's center, the NASA statement said.

The Suomi imagery also showed gravity waves (an oscillating pattern in the atmosphere) emanating out from the storm.

On Jan. 29, 2013, NASA's Aqua satellite captured an image of Cyclone Felleng at 5:14 a.m. EST that showed strong thunderstorms around the center of circulation and a 22 nautical mile-wide eye obscured by high clouds. The western edge of the storm wass approaching Madagascar (left). (Image credit: NASA Goddard MODIS Rapid Response Team)

NASA's Aqua satellite also took a look at the cyclone and produced an image in the visible light spectrum. This image also showed the strength of Felleng's storms and that its western edge was approaching Madagascar.

Felleng currently has maximum sustained winds of 132 mph (213 kph), with gusts up to 161 mph (259 kph), according to the Joint Typhoon Warning Center, run by the U.S. Navy and Air Force. The storm will be taking a turn to the south, running parallel to the Madagascar coast in the coming days, JTWC predictions show, running between it and the island of La Reunion.

This story was provided by OurAmazingPlanet, a sister site to Reach Andrea Thompson at and follow her on Twitter @AndreaTOAP. Follow OurAmazingPlanet on Twitter @OAPlanet. We're also on Facebook and Google+.
