Space History Photo: Noordung's Three-Unit Space Station Concept

By NASA Archives
published

international space station, space station concepts, Freedom, space history photos
A 1929 image depicting a three-unit space drawn by Hermann Noordung. (Image credit: NASA.)

In this historical photo from the U.S. space agency, a 1929 Hermann Noordung image depicts a three-unit space station as seen from a space ship. Hermann Potocnik (1892-1929), also known as Herman Noordung, created the first detailed technical drawings of a space station.

The three units were the habitat, the machine room, and the observatory, each connected by an umbilical. The Earth is in the background, approximately 26,000 miles away. The station in this image is roughly above Cameroon's southern tip, in a geosynchronous orbit on the median of Berlin.

[Far Out Space Station Concepts by NASA (Gallery )]

Each weekday, SPACE.com looks back at the history of spaceflight through photos (archive).

Join our Space Forums to keep talking space on the latest missions, night sky and more! And if you have a news tip, correction or comment, let us know at: community@space.com.
